Mercury EK-1550

Name: Mercury EK-1550
Brand: Posiflex
SKU: C137
Availability: OutOfStock

Seria Mercury EK-1500 vine cu un ecran tactil PCAP de 15 inchi, mod peisaj cu raport de aspect 4:3 și opțiuni flexibile de implementare.

Poate fi adaptat cu ușurință pentru a găzdui o mare varietate de periferice, servind astfel diverse aplicații pe piața verticală.

Cod Produs: C137 Ai nevoie de ajutor? 0264-414355 / 0751017741

Specification
Processor	Intel KabyLake-U i3-7100U; Intel KabyLake-U i5-7300U
System Memory	DDR4 SO-DIMM slot x 1, max. 16 GB
Storage Device	M.2 SSD [SATA Signal Only] x 1
Intel vPro Support	Core i3: N/A Core i5: Optional
TPM Support	Optional
Power Supply	12V/60W x 1 + 24V/60W x 1
OS Support	Windows 10 IoT 64 bit
Serial Port	3, DB9 x 1 + RJ50 x 2, 5V/12V support on all COM ports
Standard USB Port	8, USB 3.0 x 2 + USB 2.0 x 6
OTG USB	N/A
Display Port	HDMI x 1
LAN Port	10/100/1000 Mb x 2
Audio	Internal 3W speaker x 2
Internal Expansion Slot	M.2 x 1

Display & Touch
LCD	15"
Resolution	1024 x 768
Touch	True-flat PCAP touch with multi-touch support

Physical Dimension
Dimension (W x D x H in mm)	Countertop version (Landscape): 395 x 395 x 550 Floorstanding version (Landscape): 500 x 500 x 1325
Weight (N. W. in kg)	Countertop version: 18.8 Floorstanding version: 31

Environmental
Operating Condition	0°C - 40°C, 20%RH - 90%RH
Storage Condition	-20°C - 70°C, 10%RH - 90%RH

Standard Components
Status Indicator	-
Proximity Sensor	1. Range from 45cm ~ 80cm (for dark color object) 2. Range from 45cm ~ 150cm (for light color object)
Camera	1MP wide angle camera
Printer	3" thermal printer w/auto cutter, 200 mm/sec (max.)

Optional Components
Status Indicator	RGB Color LED Indicator
WiFi	USB dongle (cannot coexist with 4G/LTE)
Scanner	2D barcode scanner
EMV Payment Device Bracket Support*	Custom bracket support for various EMV payment devices (Posiflex does not sell the EMV payment devices, but can provide bracket support with an additional charge)
MSR	N/A
Fingerprint Sensor	Optical type
NFC/RFID Reader	Support ISO/IEC 14443-A&B (MIFARE), JIS x 6319-4 (Felica), ISO/IEC 15693, NFC protocols - tag read/write (ISO/IEC-18092)
4G / LTE Communication	N/A
PowerGuard	N/A
Optional Items for Pedestal PT-200BC	N/A
Optional Item for Pedestal PT-300	N/A
Default Items for Pedestal PT-500	N/A
